Small Wind Turbine Generator 300w 3 Blades S7 Series 12v 24v Wind Generators and Windmill
Description
SPECIFICATIONS
Application: Wind Power System
Blades Material: 3pcs
Brand Name: Feng Teng
Generator case: Casting aluminum alloy
Model: FT-300S7
Model Number: FT-S7
Output Voltage: 12v 24v
Place of Origin: Jiangsu, China
Rated Power: 300w
Rated power: 300W
Rated voltage: 12/24V
Rated wind speed: 11~13m/s
Rotor Diameter: 1200mm
Start-up wind speed: 2.5m/s
Wind turbine type: Directly Drive Wind Power
3 blades 600mm S7 series 12v 24v wind turbine generator 300w
1. The wind turbines use ultra-light composite material
2. The headpiece can be arbitrary rotated with anti-winding ability and automatically turned protection when faced with strong winds.
3. As high efficiency, they can be made hybrids system with solar panel.
|
Model |
FT-300S7 |
|
Rated power |
300W |
|
Maximum power |
310W |
|
Rated voltage |
12/24V |
|
Start-up wind speed |
2.5m/s |
|
Rated wind speed |
11~13m/s |
|
Survival wind speed |
45m/s |
|
Weight |
6.5kg |
|
Wheel diameter |
1200mm |
|
Number of blades |
3 blades |
|
Blades material |
Nylon fiber |
|
Generator type |
Three phase permanent magnet AC synchronous generator |
|
Magnet material |
NdFeB |
|
Generator case |
Casting aluminum alloy |
|
Control system |
Electromagnet/wind wheel yaw |
|
Speed regulation |
Automatically adjust windward direction |
|
Working temperature |
-40°C - 80°C |
|
Design life |
20 y |
|
Certificates |
CE, ISO14001, ISO 9001 |
Description :
1. Simple structure, running stably, power supply for city lamp, monitoring and home.
2. Small size and flexibility, beautiful curve, low noise and environmental harmony.
3. Anti-Rust, Anti-Corruption Damp-Proof, Water-Proof, Stand-Proof.
4. Brand New in box
5. CE Certificate
6. ISO9001:2000 Quality Certification
7. Large power, low volume, high efficiency
8. Nylon fiber or FRP blades, high efficiency of anti-wind ability, moves mutely and steadily
9. Blades with the ability of automatically stall protection under strong wind
Product Display
Project:
Product Features:
1. Applications Of Wind Generator
A. home and remote cabin
B. Telecommunication tower
C. Solar &wind hybrid system
D. Marine boat& yachts
E. Monitoring station
F. Water pumping
2. Features Of Wind Generator
A. Start in Breeze Wind, Quiet
B. Aluminum Die-Casting body, Durable
C. PHELPA DODGE COPPER Wire, NdFeB PMG
D. Carbon Fiber Blades, Aerodynamic Design
E. Maintenance free, only two Moving parts
3. Advange Of Wind Generator
Customized--We are the manufacturer! sample &OEM&ODM are available!
Safety--We have own test chart, all of our products have been rigorously tested in the factory.
Certification--We have CE, FCC, ROHS and quality management system certification.
High Quality --Our company uses the most advanced equipment to make the best quality products.
Packing list:
1 unit 400w wind turbine (pole is not included)
1 unit 12v/24v controller
1 unit user manuel
Packed in cartons with inner foam protection.
1. 24-hour Online service
Please feel free to contact us. Our sales team will provide you with 24 hours better pre-sale,
2. Competitive price
All of our products are supplied directly from factory. So the price is very competitive.
3. Warranty
All products have a three-year warranty.
4. OEM/ODM
With 10-year experiences in this field, we can provide customers with professional suggestion
To promote common development.
5. Distributor
The company now recruit distributor and agent all over the world. Prompt delivery and professional after-sales service are our priority, which makes us to be your reliable partner.
