SPECIFICATIONS
BMS functions: over-current, over-discharge, over-charge, short-circuit,
Brand Name: BATTIS POWER
Certification: CE,Dot,EAC,EPA,FCC,GMP,RoHS,TGA,UL,KC,pse,weee,NONE
Charger: with charger
Charging method: CC/CV
High-concerned chemical: none
Model Number: battis
Nominal Capacity: >3500mAh
Origin: Mainland China
Replacement Battery: Yes
Set Type: Charger Sets
Size: Prismatic,depend on capacity
Type: LiFePO4
Warm noted: If you are in EU, United States, Canada etc. the delivery time is about 50-69days.
If you need it urgently, please feel free to contact us !
2KW 3KW 5KW Wall Mounted 24V 48V 100ah 150ah 200ah 50ah Lithium Lifepo4 Battery for Energy Storage PV Household Inverter
24V Specifications:
Nominal Voltage : 24V
Rate Capacity :100Ah/150Ah/200Ah/300Ah
Energy : 2400Wh/3600Wh/4800Wh/7200Wh/
Cycle Life : ≤6000 times @0.2C80% DOD
Self discharge rate: <3%@0.2C
Discharge efficiency: 96-99%@1C
Max Charging Voltage : 29.2V
Charging mode: Charge to 29.2V at 0.2C, then adjust the charging current to 0.02C
Charging current: Stad 10A ,max 50A
Charging off voltage：20V+0.2V
Continuous discharge current：
100A about 2.5KW for 100Ah battery、200A about 5KW for 150Ah-300ah battery
Discharge cut-off voltage: 21V
Charging temperature : 0~45 ℃
Discharge temperature : -20 ~ 60 ℃
Storage temperature : -20 ~ 45 ℃
Environmental humidity requirement: ≤ 65% RH
Communication Protocol: RS485/CAN
Bluetooth APP: Yes , monitor your battery status in real time!
Size & Weight:
24V 100Ah: 380*160*350mm
24V 150Ah: 380*200*320mm
24V 200Ah: 380*230*350mm
24V300Ah: 550*360*200mm
48V Specifications:
Nominal Voltage : 51.2V
Rate Capacity : 50Ah/100Ah/150Ah/200Ah
Energy : 2400Wh/4800Wh/7200Wh/9600Wh
Cycle Life : ≤6000 times @0.2C80% DOD
Self discharge rate: <3%@0.2C
Discharge efficiency: 96-99%@1C
Max Charging Voltage : 58.4V
Charging mode: Charge to 54.8V at 0.2C, then adjust the charging current to 0.02C
Charging current: Stad 10A ,max 50A
Charging off voltage：55.5V+0.2V
Continuous discharge current：
100A about 5KW for 50-100Ah battery、200A about 10KW for 150Ah-200ah battery
Discharge cut-off voltage: 40V
Charging temperature : 0~45 ℃
Discharge temperature : -20 ~ 60 ℃
Storage temperature : -20 ~ 45 ℃
Environmental humidity requirement: ≤ 65% RH
Communication Protocol: RS485/CAN
Bluetooth APP: Yes , monitor your battery status in real time!
Size & Weight:
50Ah: 400*300*180mm with 100ABMS≈5KW
100Ah: 450*340*190mm with100A BMS≈5KW
150Ah: 500*340*200mm with 200A BMS≈10KW with 200A BMS≈10KW
200Ah:550*380*190mm with 200A BMS≈10KW
Package List :
1. 1pcs 48V Lifepo4 Battery , BMS Built in with RS485/CAN communication/Bluetooth APP.
2. 1pcs 58.4V 10A Charger for 50-150Ah Battery / 20A Charger for 200Ah Battery
( choose one EU/US/UK/AU AC Charger plug we can offer )
